BRY-MILES-W2-WHT-30W-4000K-IP54 WALL LIGHT

BG36-10110

BRY-MILES-W2-WHT-30W-4000K-IP54 WALL LIGHT - 1

BRY-MILES-W2-WHT-30W-4000K-IP54 WALL LIGHT - 2

BRY-MILES-W2-WHT-30W-4000K-IP54 WALL LIGHT - 3

BRY-MILES-W2-WHT-30W-4000K-IP54 WALL LIGHT - 4

BRY-MILES-W2-WHT-30W-4000K-IP54 WALL LIGHT - 5

BRY-MILES-W2-WHT-30W-4000K-IP54 WALL LIGHT - 6

BRY-MILES-W2-WHT-30W-4000K-IP54 WALL LIGHT - 7

BRY-MILES-W2-WHT-30W-4000K-IP54 WALL LIGHT - 8

BRY-MILES-W2-WHT-30W-4000K-IP54 WALL LIGHT - 9

Family Products

General Characteristics

Model No

BG36-10110

Main Family

Outdoor Lighting

Sub Family

Led Wall Light

Type

Wall Light

Body Color

White

Lamp Shape

Non-Directional

Dimmable

Not-Dimmable

Light Source

LED

Warranty

2 Years

Class

CLASS II

IP

IP54

IK

IK05

Product Characteristics

Wattage

30 w

Color Temperature

4000K

Quse Lumen

3300 lm

Color Rendering Index (CRI)

≥70

Energy Efficiency Level

E

Beam Angle

120⁰

Color Category

Neutral White

Electrical Characteristics

Lifetime

20000 h

Voltage

220-240V

Power Factor

>0,9

Material

PC

Working Temperature

-20⁰C ~ +40⁰C

Frequency

50/60Hz

Dimensions & Weight

P. Length

228 mm

P. Width

140 mm

P. Height

185 mm

Weight

566 g

Sensor Informations

Sensor Type

Motion

Detection Distance

≤10 mt

Detection Angle

110° Degrees

Installation Height

2-3 mt

Time Delay

10 sec.-1 min.

Lux

10-1000 lux

Package Informations

N.W.

4,5 kg

G.W.

5,8 kg

PCS/CTN

8

Length

48 cm

Width

24 cm

Height

30 cm

EAN

5949097739644

BG36-10110 DATASHEET
